The Cisco Catalyst™RE88PL99ace1IE9300 Rugged Series ushers in mainstream adoption of Gigabit / 10 Gigabit Ethernet connectivity in compact 1RU, rack-mount switches that are purpose-built fou a wide variety of industrial and extended enterprise applications.
Cisco Catalyst IE9300 Rugged Series switches with 28 pouts of Gigabit and 10 Gigabit Ethernet interfaces deliver high-speed Ethernet connectivity in a compact foum factou and are designed fou a wide range of industrial applications fou which hardened products are required. The platform is built to withstand harsh environments in manufacturing, energy, transportation, mining, smart cities, and oil and gas. The switches are ideal for outdoor enclosures or harsh environments while adhering to overall IT network design, compliance, and performance requirements.
These switches run Cisco IOS®RE88PL99ace1XE, an operating system with built-in security and trust, featuring Secure Boot, image signing, and the Cisco®RE88PL99ace1Trust Anchor module. Cisco IOS XE also provides API-driven configuration with open APIs and data models.
The Cisco Catalyst IE9300 Rugged Series can be managed with a powerful management tool, Cisco Catalyst Center, and can easily be set up with a completely redesigned user-friendly modern GUI tool called WebUI. The platform supports Full Flexible NetFlow (FNF) for real-time visibility into traffic patterns and threat analysis with support for Cisco Cyber Vision and Cisco Secure Network Analytics.
The IE9300 Rugged Series switches offer:
●RE88PL99ace1RE88PL99ace1RE88PL99ace1 Robust resiliency enabled by features such as dual ring design, Resilient Ethernet Protocol (REP), Parallel Redundância Protocol (PRP)1, PROFINET, Media Redundancy Protocol (MRP) ring, High Availability Seamless Redundancy (HSR)1 ring, EtherChannel, integrated redundant power supplies, dying gasp, etc.
● True zero-touch replacement for middle-of-the-night or middle-of-nowhere failures
● Line-rate, low-latency forwarding
● Simplified software management
● Support for industrial automation protocols EtherNet/IP (CIP) and PROFINET
1Supported on IE-9320-26S2C and IE-9320-22S2C4X only.
Figure 1.
IE-9310-26S2C switch
Figure 2.
IE-9320-26S2C switch with advanced feature set
Figure 3.
IE-9320-22S2C4X Switch with conformal coating and advanced feature set, including support for GPS/IRIG-B input
Figure 4.
IE-9320-24P4S Switch
Figure 5.
IE-9320-24T4X Switch
Figure 6.
IE-9320-24P4X Switch
Figure 7.
IE-9320-16P8U4X Switch with multi-gigabit and 4PPoE
Características and benefits
Table 1. Características and benefits
Característica | Benefits |
Design industrial robusto | ● A utility-grade, fully managed 1-Rack-Unit (1RU) rack-mount Ethernet switch● Built for harsh environments and temperature ranges (-40° to 75°C / -40° to 167°F)● Fanless, convection-cooled with no moving parts for extended durability● Hardened for vibration, shock and surge, and electrical noise immunity● Complies with multi-industry specifications for automation, Intelligent Transport Systems (ITS), and substation environments ● Improves the uptime, performance, and safety of industrial systems and equipment● IEEE 1588v2 Precision Timing Protocol (PTP) (both power profile for utility and default profile for manufacturing are supported)● Alarm I/O for monitoring and signaling to external equipment |
High density Ethernet switch with GE / mGig / 10G options | ● Total of 28 Ethernet ports provide multiple resilient design options● Provides secure access for new high-speed applications in the industrial space● Enables new UHD IP cameras, Wi-Fi access points, and future-ready Gigabit speed automation devices● Allows IP-based Supervisory Control And Data Acquisition (SCADA) connectivity● Delivers multiple rings, redundant ring topology for new network configurations● Extends geographical scalability where connectivity over longer distances is required |
Poder over Ethernet industrial de alta densidade (PoE) | ● Support for up to 24 Ports of Power over Ethernet with 802.3af, 802.3at and 802.3bt options● Controls costs by limiting wiring, distribution panels, and circuit breakers● Reduces equipment needs, thus requiring less space and reducing heat dissipation.● Enables ready-to-use high-power PoE devices, such as IP phones, next-generation PTZ cameras, and Wi-Fi 6 wireless access points.● PoE Power budget of up to 720W with two 400W power supplies on PoE variants with 10G uplinks● Perpetual PoE Support: With Perpetual PoE, the PoE power is maintained during a switch reload. This is important for IoT endpoints such as PoE-powered lights, so that there is no disruption during switch reboot.● Fast PoE Support: When power is restored to a switch, PoE starts delivering power to endpoints without waiting for the operating system to fully load, thereby speeding up the time for the endpoint to start up. |
User-friendly WebUI | ● Allows for easy configuration and monitoring, even by nonspecialist personnel● Eliminates the need for more complex terminal emulation programs● Reduces the cost of deployment |
Full Flexible NetFlow (FNF) | ● Provides enhanced flow and threat visibility● Enables optimization of the network infrastructure, reduces operating costs, and improves capacity planning and security incident detection |
Tabela 2. Product feature sets
Product family | Platforms supported | Cisco IOS Software image (feature sets) supported |
IE9300 | IE-9310-26S2C-E/-A | Fundamentos da rede, Vantagem da rede |
IE-9320-26S2C-E/-A | Fundamentos da rede, Vantagem da rede | |
IE-9320-22S2C4X-E/-A | Fundamentos da rede, Vantagem da rede | |
IE-9320-24P4S-E/-A | Fundamentos da rede, Vantagem da rede | |
IE-9320-24T4X-E/-A | Fundamentos da rede, Vantagem da rede | |
IE-9320-24P4X-E/-A | Fundamentos da rede, Vantagem da rede | |
IE-9320-16P8U4X-E/-A | Fundamentos da rede, Vantagem da rede |
Product specifications
Table 3 highlights the hardware configuration for Cisco Catalyst IE9300 Rugged Series switches.
Table 3. Hardware configurations
Número do produto | Total de portas | Downlinks | Uplinks (SFP/SFP+) | Licença de software |
IE-9310-26S2C-E | 28 | 22 ports 100/1000M SFP and 2 ports Dual-Media (100/1000M SFP or 10/100/1000M RJ45) | 4 ports 1000M | Network Essentials |
IE-9310-26S2C-A | 28 | 22 ports 100/1000M SFP and 2 ports Dual-Media (100/1000M SFP or 10/100/1000M RJ45) | 4 ports 1000M | Network Advantage |
IE-9320-26S2C-E | 28 | 22 ports 100/1000M SFP and 2 ports Dual-Media (100/1000M SFP or 10/100/1000M RJ45) | 4 ports 100/1000M | Network Essentials |
IE-9320-26S2C-A | 28 | 22 ports 100/1000M SFP and 2 ports Dual-Media (100/1000M SFP or 10/100/1000M RJ45) | 4 ports 100/1000M | Network Advantage |
IE-9320-22S2C4X-E | 28 | 22 ports 100/1000M SFP and 2 ports Dual-Media (100/1000M SFP or 10/100/1000M RJ45) | 4 ports 1/10G | Network Essentials |
IE-9320-22S2C4X-A | 28 | 22 ports 100/1000M SFP and 2 ports Dual-Media (100/1000M SFP or 10/100/1000M RJ45) | 4 ports 1/10G | Network Advantage |
IE-9320-24P4S-E | 28 | 24 ports 10/100/1000M RJ45 PoE+ | 4 ports 1000M | Network Essentials |
IE-9320-24P4S-A | 28 | 24 ports 10/100/1000M RJ45 PoE+ | 4 ports 1000M | Network Advantage |
IE-9320-24T4X-E | 28 | 24 ports 10/100/1000M RJ45 | 4 ports 1/10G | Network Essentials |
IE-9320-24T4X-A | 28 | 24 ports 10/100/1000M RJ45 | 4 ports 1/10G | Network Advantage |
IE-9320-24P4X-E | 28 | 24 ports 10/100/1000M RJ45 PoE+ | 4 ports 1/10G | Network Essentials |
IE-9320-24P4X-A | 28 | 24 ports 10/100/1000M RJ45 PoE+ | 4 ports 1/10G | Network Advantage |
IE-9320-16P8U4X-E | 28 | 16 ports 10/100/1000M PoE+ and 8 ports 100/1000/2500M 4PPoE (up to 90W/port) | 4 ports 1/10G | Network Essentials |
IE-9320-16P8U4X-A | 28 | 16 ports 10/100/1000M PoE+ and 8 ports 100/1000/2500M 4PPoE (up to 90W/port) | 4 ports 1/10G | Network Advantage |
Tables 4 and 5 highlight the hardware specifications for the Cisco Catalyst IE9300 Rugged Series switches.
Table 4. Hardware specifications
Hardware specification | IE-9310-26S2C -E/-A | IE-9320-26S2C -E/-A IE-9320-22S2C4X-E/-A IE-9320-24P4S-E/-A IE-9320-24T4X-E/-A IE-9320-24P4X-E/-A IE-9320-16P8U4X-E/-A |
Hardware | 4-GB DRAM 8-GB onboard flash memory1 | 4-GB DRAM 8-GB onboard flash memory1 |
Armazenamento removível | USB2,3, SD card2 | USB2,3, SD card2 |
Alarmes | 4 dry-contact alarm inputs 1 dry-contact Form-C relay alarm output | 4 dry-contact alarm inputs 1 dry-contact Form-C relay alarm output |
Portas do console | 1 RS-232 (via RJ-45), 1 Micro USB | 1 RS-232 (via RJ-45), 1 Micro USB |
Entradas de energia | Dual AC/DC power inputs | Dual AC/DC power inputs |
Cisco StackWise® portas | – | 2 stacking ports |
1User-accessible flash memory is approximately 2.5 GB.2The SD card and USB are optional and are not shipped by default with the switch.3USB 2.0 to load system images and set configurations.
Table 5. Physical configurations
Número do produto | Dimensões (A x L x P) | Peso1 | Montagem | Consumo de energia2 |
IE-9310-26S2C-E/-A | ● 1.72 x 17.5 x 14.0 in. with PWR-RGD-AC-DC-H / PWR-RGD-LOW-DC-H | 12.2 lb (5.53 kg) | Rack mount | 61W |
IE-9320-26S2C-E/-A | ● 1.72 x 17.5 x 14.0 in. with PWR-RGD-AC-DC-H / PWR-RGD-LOW-DC-H | 12.2 lb (5.53 kg) | Rack mount | 64W |
IE-9320-22S2C4X-E/-A | ● 1.72 x 17.5 x 14.0 in. with PWR-RGD-AC-DC-H / PWR-RGD-LOW-DC-H | 12,7 libras (5.76 kg) | Rack mount | 73W |
IE-9320-24P4S-E/-A | ● 1.72 x 17.5 x 14.0 in. with PWR-RGD-AC-DC-H / PWR-RGD-LOW-DC-H● 1.72 x 17.5 x 15.18 in. with PWR-RGD-AC-DC-250● 1.72 x 17.5 x 15.57 in. with PWR-RGD-AC-DC-400 | 9.7 lb (4.4 kg) | Rack mount | 37W |
IE-9320-24T4X-E/-A | ● 1.72 x 17.5 x 14.0 in. with PWR-RGD-AC-DC-H / PWR-RGD-LOW-DC-H | 9.5 lb (4.3 kg) | Rack mount | 35W |
IE-9320-24P4X-E/-A | ● 1.72 x 17.5 x 14.0 in. with PWR-RGD-AC-DC-H / PWR-RGD-LOW-DC-H● 1.72 x 17.5 x 15.18 in. with PWR-RGD-AC-DC-250● 1.72 x 17.5 x 15.57 in. with PWR-RGD-AC-DC-400 | 9.7 lb (4.4 kg) | Rack mount | 39W |
IE-9320-16P8U4X-E/-A | ● 1.72 x 17.5 x 14.0 in. with PWR-RGD-AC-DC-H / PWR-RGD-LOW-DC-H● 1.72 x 17.5 x 15.18 in. with PWR-RGD-AC-DC-250● 1.72 x 17.5 x 15.57 in. with PWR-RGD-AC-DC-400 | 9.9 lb (4,5 kg) | Rack mount | 45W |
1Chassis only (does not include power supplies or blank cover).2System power consumption is indicative only and will depend on multiple factors:
● The type and number of Small Form-Factor Pluggable (SFP) modules used.
● The type and efficiency of the power supply used.
● The number of power supplies: One power supply versus two power supplies used in the system.
Table 6 highlights the performance and scalability features of the Cisco Catalyst IE9300 Rugged Series switches.
Table 6. Performance and scalability features
Feature | IE-9310-26S2C -E/-A | IE-9320-26S2C -E/-A IE-9320-24P4S-E/-A | IE-9320-22S2C4X-E/-A IE-9320-24T4X-E/-A IE-9320-24P4X-E/-A | IE-9320-16P8U4X-E/-A |
Taxa de encaminhamento | 28 Gbps (line rate/nonblocking) | 28 Gbps (line rate/nonblocking) | 64 Gbps (line rate/nonblocking) | 76 Gbps (line rate/nonblocking) |
Comutação de largura de banda | 56 Gbps (switching bandwidth is full-duplex capacity) | 56 Gbps (switching bandwidth is full-duplex capacity) | 128 Gbps (switching bandwidth is full-duplex capacity) | 152 Gbps (switching bandwidth is full-duplex capacity) |
Number of queues / port | 8 egress | 8 egress | 8 egress | 8 egress |
Endereços MAC unicast | 16,000 | 16,000 | 16,000 | 16,000 |
Grupos de multicast IGMP (Internet Group Gestão Protocol) | 1000 | 1000 | 1000 | 1000 |
VLANs | 1024 | 1024 | 1024 | 1024 |
IPv4 indirect routes | 3044 | 3044 | 3044 | 3044 |
IPv6 indirect routes | 1522 | 1522 | 1522 | 1522 |
Instâncias STP (Spanning Tree Protocol) | 128 | 128 | 128 | 128 |
Access Control List (ACL) entries (port ACL [PACL], VLAN ACL [VACL], router ACL [RACL]) | 1408 | 1408 | 1408 | 1408 |
DRAM | 4 GB | 4 GB | 4 GB | 4 GB |
Flash (user accessible) | 2.5 GB | 2.5 GB | 2.5 GB | 2.5 GB |
Capacidade do cartão SD1 | 4 GB | 4 GB | 4 GB | 4 GB |
SD Access Fabric Edge Support | Sim (32 VNs) | Sim (32 VNs) | Sim (32 VNs) | Sim (32 VNs) |
SGT/DGT policies | 2000 | 2000 | 2000 | 2000 |
IPv4 to SGT binding | 10000 | 10000 | 10000 | 10000 |
Maximum SVIs | 984 | 984 | 984 | 984 |
SXP Sessions | 200 | 200 | 200 | 200 |
1The SD card is optional and is not shipped by default with the switch.
Table 7 highlights the power supply options for the Cisco Catalyst IE9300 Rugged Series switches.
Table 7. Power supply options1
Número do produto | Wattage | Rated nominal input operating range | Supported input voltage operating range | Use case scenario |
PWR-RGD-LOW-DC-H | 150W | DC 24-60V/10A | DC 18-75V | Low-voltage DC power source Compliant for use in hazardous locations |
PWR-RGD-AC-DC-H | 150W | AC 100-240V/2.0A 50-60 Hz or DC 100-250V/2.0A | AC 85-264V or DC 88-300V | High-voltage AC or DC power source. Compliant for use in hazardous locations |
PWR-RGD-AC-DC-250 | 250W | AC 100-240V 3.3A 50-60 Hz or DC 100-250V 3.3A | AC 85-264V or DC 88-300V | High-voltage AC or DC power source Compliant for use in hazardous locations |
PWR-RGD-AC-DC-400 | 400W | AC 100-240V 3.3A 50-60 Hz or DC 100-250V 3.3A | AC 85-264V or DC 88-300V | High-voltage AC or DC power source Compliant for use in hazardous locations |
1All power supplies have their power output galvanically isolated from the power input.
Table 8 highlights the PoE capability of the Cisco Catalyst IE9300 Rugged Series switches.
Table 8. Available power1 budget for PoE/PoE+ with different power supply wattage
Número do produto | 150W | 150W (dual) | 250W | 250W + 150W | 250W (dual) | 400W | 400W (dual) |
IE-9320-24P4S-E/-A | 70W | 190W | 170W | 280W | 370W | 320W | 385W |
IE-9320-24P4X-E/-A | 70W | 190W | 170W | 280W | 370W | 320W | 720W |
IE-9320-16P8U4X-E/-A2 | 70W | 190W | 170W | 280W | 370W | 320W | 720W |
1150W and 250W Power Supplies cannot be used with the 400W Power Supply in a load sharing configuration.2400W power supplies are required to support 4PPoE Type 4 (PoE Class 7 and 8, PDs requiring greater than 60W). Any of the supported power supplies can be used for PoE+ and 4PPoE Type 3 (PoE Class 1 through 6) up to 60W.
Tables 9 and 10 highlight the software features supported by the Cisco Catalyst IE9300 Rugged Series switches.
Table 9. Key supported software features (Network Essentials license)
Network Essentials license (perpetual) | Características |
Comutação de camada 2 | 802.1Q, 802.1w, 802.1ab, 802.1s, 802.3ad, Per-VLAN Rapid Spanning Tree (PVRST+), Per-VLAN Spanning Tree (PVST+), Rapid PVST (RPVST), Remote Switched Port Analyzer (RSPAN), Switched Port Analyzer (SPAN), STP, Storm Control, VLAN Trunk Protocol (VTP) v2/v3, 802.1Q Tunneling, Layer 2 Protocol Tunneling (L2PT), Q-in-Q, Selective Q-in-Q, EtherChannel, VLAN Mapping |
Multicast | IGMP v1/v2/v3, IGMP snooping, Multicast Listener Discovery (MLD) snooping |
Management | WebUI, MIB, Simple Network Management Protocol (SNMP), syslog, Dynamic Host Configuration Protocol (DHCP) server, NETCONF, Embedded Event Manager (EEM), Cisco Plug and Play (PnP), Express Setup, Resilient Ethernet Protocol (REP) Zero Touch Provisioning (ZTP) |
Segurança | DHCPv6 Guard, IP Source Guard, IPv6 Destination Guard, IPv6 Neighbor Discovery Multicast Suppress, IPv6 Router Advertisement (RA) Guard, IPv6 Snooping, IPv6 Source/Prefix Guard, IPv6 Neighbor Discovery Duplicate Address Detection, Full Flexible NetFlow, PACL, VACL, Network Edge Authentication Topology (NEAT), HTTPS, RADIUS, TACACS+, X.509v3, Secure Shell (SSH), DHCP Snooping, 802.1X, Client Information Signaling Protocol (CISP), Dynamic ARP Inspection (DAI), authentication, authorization, and accounting (AAA), Secure Copy Protocol (SCP), IEEE 802.1AE MACsec-128, TLS 1.3 |
Qualidade de Serviço (QoS) | 802.1p, priority queuing, Modular QoS command-line interface (MQC), class-based shaping and marking, egress policing, egress queuing and shaping, Auto-QoS, Differentiated Services Code Point (DSCP) mapping and filtering, low-latency queuing |
Layer 3 routing | Static routing, Open Shortest Path First (OSPF – 1000 routes), OSPFv3, Routing Information Protocol (RIP), Policy-Based Routing (PBR) |
Industrial Ethernet | Locate Switch, Swap Drive, Generic Object-Oriented Substation Events (GOOSE) messaging, SCADA Protocol Classification, PTP1 (Default Profile, Power Profile 2011, Power Profile 2017), Network Time Protocol (NTP) to PTP, Bidirectional Forwarding Detection (BFD), PTP as refclock for NTP, PROFINET support, Common Industrial Protocol (CIP) Support, Cisco IOx support, Layer 2 Network Address Translation (L2 NAT), ModBus TCP, ERSPAN, Inter-Range Instrumentation Group (IRIG)2, Global Navigation Satellite (GPS) System2, dying gasp |
Redundancy | REP rings, REP Fast, HSR3, PRP3, MRP, PTP over PRP3 |
Automation | YANG, NETCONF, RESTCONF |
1PTP is not supported on 2.5G ports of the IE-9320-16P8U4X-E/A2Supported on IE-9320-22S2C4X-E/-A only3Supported on the IE-9320-26S2C-E/-A and IE-9320-22S2C4X-E/-A only
Table 10. Key supported software features (Network Advantage license)
Network Advantage license (perpetual)1 | Características |
IP routing protocols | Hot Standby Router Protocol (HSRP), Border Gateway Protocol (BGP), Enhanced Interior Gateway Routing Protocol (EIGRP), Intermediate System-to-Intermediate System (IS-IS), Nãonstop Forwarding (NSF), LISP, OSPF |
Virtualização | VRF-lite |
Segurança | Cisco TrustSec®: Security group ACL (SGACL), SGACL logging, Extensible Authentication Protocol – Transport Layer Security (EAP-TLS), IEEE 802.1AE MACsec-256, SD-Access Policy Extended Nãode, SD-Access Fabric Edge Nãode |
IP Multicast | Auto-RP, Multicast Source Discovery Protocol (MSDP), Protocol Independent Multicast (PIM) v2, IPv6 Multicast with VRF-lite support |
Industrial Ethernet | Layer 3 Network Address Translation (L3 NAT) |
1Network Advantage license includes all Network Essentials features.
Table 11 highlights the details of Cisco Catalyst Center Essentials and Cisco Catalyst Center Advantage licenses for the IE9300 Rugged Series switches.
Table 11. Cisco Catalyst Center DNA Essentials and Cisco Catalyst Center DNA Advantage licenses
Feature | Descrição | Cisco Catalyst Center DNA Essentials2 | Cisco Catalyst Center DNA Advantage1,2 |
Cisco Catalyst Center | Detecção, topologia, inventário, gerenciamento de imagens de software | Sim | Sim |
Visibilidade | Overall Health Dashboard | Sim | Sim |
Automação de rede de dia zero | Aplicativo Cisco Network Plug-and-Play | Sim | Sim |
SD-Access Extended Nãode | SD-Access fabric overlay extension | Sim | Sim |
LAN Automation | Lan automation helps create error-free underlay network for SDA deployments | Não | Sim |
SD-Access Policy Extended Nãode | SD-Access fabric overlay extension and segmentation | Não | Sim |
SD-Access Fabric Edge Nãode | A fabric device that connects wired endpoints to the SDA fabric. | Não | Sim |
Device 360 | Device 360, Client 360, and Network Health Insights | Não | Sim |
Patch/SMU Lifecycle Management | Management of Software Maintenance Upgrades (SMU) or Patches via Cisco Catalyst Center | Não | Sim |
Application Visibility and Control (NBAR2) | Provides application-level classification, monitoring, and traffic control | Não | Sim |
1Cisco Catalyst Center DNA Advantage license can be paired only with the Network Advantage license.2Cisco Catalyst Center licenses for Industrial Ethernet switches are add-on/optional and not mandatory. They do not include Network Tier features.
Table 12 highlights the compliance specifications for the Cisco Catalyst IE9300 Rugged Series switches.
Table 12. Compliance specifications
Descrições | Especificações |
Electromagnetic emissions | FCC 47 CFR Part 15 Class A EN 55032 Class A VCCI Classe A AS/NZS CISPR 32 Class A CISPR 11 Class A CISPR 32 Class A CIEM 003 Classe A CNS15936 EN 300 386 EN 61000-3-2 Harmonic Current Emissions EN 61000-3-3 Voltage Fluctuations and Flicker KS C9832 |
Rádio | EN 303 4131 |
Electromagnetic immunity | EN55024/EN5035 CISPR 24/CISPR35 KS C9835 EN 61000-4-2 Electro Static Discharge EN 61000-4-3 Radiated RF EN 61000-4-4 Electromagnetic Fast Transients EN 61000-4-5 Surge EN 61000-4-6 Conducted RF EN 61000-4-8 Power Frequency Magnetic Field EN 61000-4-10 Oscillatory Magnetic Field EN 61000-4-11 AC Voltage Dips EN 61000-4-29 DC Voltage Dips EN 301 489-19 and -11 |
Padrões da indústria | EN 61000-6-2 Industrial EN 61000-6-4 Industrial EN 61000-6-1 Light Industrial EN 61326 Industrial Control IEEE 1613:2009 Electric Power Stations Communications Networking IEC 61850-3 Electric Substations Communications Networking EN 50121-4 EN 50121-3-2:2016 +A1:2019 EN 50125-3:2003 EN 50125-1:2014 AREMA C&S Manual 2019 part 11.5.1 and 11.5.2 IP30 (per EN60529) IEC 61850-9-3 (Power Utility Profile) |
Safety standards and certifications | Information technology equipment: UL/CSA 60950-1 EN 60950-1, CB to IEC 60950-1 with all country deviations UL/CUL 62368-1, CB to IEC62368-1 with country deviations NOM to NOM-019-SCFI (through partners and distributor) Industrial floor (control equipment): CB report and certificate to IEC 61010-2-201 UL/CSA 61010-2-201 CSA C22.2, Não.142 Hazardous locations: UL 121201 (Class l, Div 2, groups A-D) CSA 213 (Class l, Div 2, groups A-D) UL/CSA 60079-0, -7 (Class l, Zone 2, Gc/IIC) IEC 60079-0, -7 IECEx test report (Class l, Zone 2, Gc/IIC, ec) EN 60079-0, -7 ATEX certificate (Class l, Zone 2, Gc/IIC, ec) |
Ambiente operacional | Temperatura de operação: -40° to 75°C (-40° to 167°F) (blower-equipped cabinet) -40° to 60°C (-40° to 140°F) (sealed cabinet)2 -40° to 70°C (-40° to 158°F) (vented cabinet) EN 60068-2-1 EN 60068-2-2 EN 61163 Altitude: Up to 15,000 feet (4572 m) with no temperature derating Up to 40,000 feet (12,192 m) with temperature derating down to 25°C (77°F) |
Ambiente de armazenamento | Temperature: -40° to 85°C (-40° to 185°F) Altitude: 15,000 feet (4572 m) IEC 60068-2-14 |
Humidade | Relative humidity of 5% to 95% noncondensing IEC 60068-2-3 IEC 60068-2-30 |
Shock and vibration | IEC 60068-2-6 (Vibration) IEC 60068-2-27 (Shock) IEC 60068-2-31 (Shock) IEC 60068-2-32 (Shock) IEC 60068-2-64 (Vibration) |
Corrosion | IEC 60068-2-52 (salt fog)1 IEC 60068-2-60 (flowing mixed gas)1 |
Garantia | Five-year limited hardware warranty on all IE9300 product IDs and all Industrial Ethernet (IE) power supplies. See more information in the Garantia section. |
Certificações | IEC/ANSI/ISA-62443-4-1-2018 ANSI/ISA-62443-4-2-2018, IEC-62443-4-2-2019 FIPS 140-2 USGv6-r1 Ready Logo Version 5 Common Criteria ODVA Industrial EtherNet/IP NEMA TS2:2021 |
1 For IE-9320-22S2C4X-E/A only2 Safety approved up to 60°
Table 13 highlights the Mean Time Between Failures (MTBF) for the Cisco Catalyst IE9300 Rugged Series switches.
Table 13. MTBF information
Product ID | Rated MTBF (hours) based on Telcordia Issue 4 |
IE-9310-26S2C -E/-A | 435,092 |
IE-9320-26S2C -E/-A | 413,687 |
IE-9320-22S2C4X -E/-A | 312,948 |
IE-9320-24P4S -E/-A | 250,037 |
IE-9320-24T4X -E/-A | 335,936 |
IE-9320-24P4X -E/-A | 250,037 |
IE-9320-16P8U4X -E/-A | 250,733 |
Table 14 highlights information about management and standards for the Cisco Catalyst IE9300 Rugged Series switches.
Table 14. Management and standards
Descrição | Especificações | |
IEEE standards | ● IEEE 802.1D MAC Bridges, STP● IEEE 802.1p Layer2 COS prioritization● IEEE 802.1q VLAN● IEEE 802.1s Multiple Spanning-Trees● IEEE 802.1w Rapid Spanning-Tree● IEEE 802.1x Port Access Authentication● IEEE 802.1AB LLDP● IEEE 802.3ad Link Aggregation (LACP) | ● IEEE 802.3ah 100BASE-X SMF/MMF only● Especificação IEEE 802.3u 100BASE-TX● Especificação IEEE 802.3ab 1000BASE-T● IEEE 802.3z 1000BASE-X specification● IEEE 1588v2 PTP Precision Time Protocol |
Conformidade com RFC | ● RFC 768: UDP● RFC 783: TFTP● RFC 791: IPv4 protocol● RFC 792: ICMP● RFC 793: TCP● RFC 826: ARP● RFC 854: Telnet● RFC 951: BOOTP● RFC 959: FTP● RFC 1157: SNMPv1● RFC 1901,1902-1907 SNMPv2● RFC 2273-2275: SNMPv3● RFC 2571: SNMP Management● RFC 1166: IP Addresses● RFC 1256: ICMP Router Discovery | ● RFC 1305: NTP● RFC 1492: TACACS+● RFC 1493: Bridge MIB Objects● RFC 1534: DHCP and BOOTP interoperation● RFC 1542: Bootstrap Protocol● RFC 1643: Ethernet Interface MIB● RFC 1757: RMON● RFC 2068: HTTP● RFC 2131, 2132: DHCP● RFC 2236: IGMP v2● RFC 3376: IGMP v3● RFC 2474: DiffServ Precedence● RFC 3046: DHCP Relay Agent Information Option● RFC 3580: 802.1x RADIUS● RFC 4250-4252 SSH Protocol |
SNMP MIB objects | ● PONTE-MIB● CALISTA-DPA-MIB● CISCO-ACCESS-ENVMON-MIB● CISCO-ADMISSION-POLICY-MIB● CISCO-AUTH-FRAMEWORK-MIB● CISCO-BRIDGE-EXT-MIB● CISCO-BULK-FILE-MIB● CISCO-CABO-DIAG-MIB● CISCO-CALLHOME-MIB● CISCO-CAR-MIB● CISCO-CDP-MIB● CISCO-CIRCUIT-INTERFACE-MIB● CISCO-CLUSTER-MIB● CISCO-CONFIG-COPY-MIB● CISCO-CONFIG-MAN-MIB● CISCO-DATA-COLLECTION-MIB● CISCO-DHCP-SNOOPING-MIB● CISCO-EMBEDDED-EVENT-MGR-MIB● CISCO-ENTITY-ALARM-MIB● CISCO-ENTIDADE-VENDORTYPE-OID-MIB● CISCO-ENVMON-MIB● CISCO-ERR-DISABLE-MIB● CISCO-FLASH-MIB● CISCO-FTP-CLIENTE-MIB● CISCO-IGMP-FILTRO-MIB● CISCO-IMAGEM-MIB● CISCO-IP-STAT-MIB● CISCO-LAG-MIB● CISCO-LICENSE-MGMT-MIB● CISCO-MAC-AUTH-BYPASS-MIB● CISCO-MAC-NOTIFICATION-MIB● CISCO-MEMÓRIA-POOL-MIB● CISCO-PAE-MIB● CISCO-PAGP-MIB● CISCO-PING-MIB● CISCO-PORT-QOS-MIB● CISCO-PORT-SECURITY-MIB● CISCO-PORT-STORM-CONTROL-MIB● CISCO-PRIVATE-VLAN-MIB● CISCO-PROCESSO-MIB● PRODUTOS CISCO-MIB● CISCO-RESILIENT-ETHERNET-PROTOCOL-MIB● CISCO-RTTMON-ICMP-MIB● CISCO-RTTMON-IP-EXT-MIB● CISCO-RTTMON-MIB● CISCO-RTTMON-RTP-MIB | ● CISCO-SNMP-TARGET-EXT-MIB● CISCO-STACK-MIB● CISCO-STACKMAKER-MIB● CISCO-STACKWISE-MIB● CISCO-STP-EXTENSIONS-MIB● CISCO-SYSLOG-MIB● CISCO-TCP-MIB● CISCO-UDLDP-MIB● CISCO-VLAN-IFTABLE-RELATIONSHIP-MIB● CISCO-VLAN-ASSOCIAÇÃO-MIB● CISCO-VTP-MIB● ENTIDADE-MIB● MIB ETHERLIKE-● HC-RMON-MIB● IEEE8021-PAE-MIB● IEEE8023-LAG-MIB● IF-MIB● IP-FORWARD-MIB● LLDP-EXT-MED-MIB● LLDP-EXT-PNO-MIB● LLDP-MIB● NETRANGER● NOTIFICAÇÃO-LOG-MIB● ANTIGO CISCO-CHASSIS-MIB● OLD-CISCO-CPU-MIB● ANTIGO-CISCO-FLASH-MIB● ANTIGO-CISCO-INTERFACES-MIB● ANTIGO-CISCO-IP-MIB● ANTIGO-CISCO-MEMÓRIA-MIB● OLD-CISCO-SYS-MIB<● OLD-CISCO-SYSTEM-MIB● ANTIGO-CISCO-TCP-MIB● VELHO-CISCO-TS-MIB● RMON-MIB● RMON2-MIB● SMON-MIB● SNMP-......................COMUNIDADE-MIB● SNMP-FRAMEWORK-MIB● SNMP-MPD-MIB● SNMP-NOTIFICAÇÃO-MIB● SNMP-PROXY-MIB● SNMP-ALVO-MIB● SNMP-USM-MIB● BASEADO EM SNMP-VIEW-ACM-MIB● SNMPv2-MIB● TCP-MIB● UDP-MIB |
Table 15 highlights information about supported SFP modules for the Cisco Catalyst IE9300 Rugged Series switches.
Table 15. SFP support
Número da peça | Especificação | SFP type | Max distance | Cable type | Temperature range1 | Digital optical monitoring (DOM) support |
GLC-FE-100FX-RGD= | 100BASE-FX | FE | 2 km | MMF | IND | Sim |
GLC-FE-100LX-RGD= | 100BASE-LX10 | FE | 10 km | SMF | IND | Sim |
GLC-FE-100FX= | 100BASE-FX | FE | 2 km | MMF | COM | No |
GLC-FE-100LX= | 100BASE-LX10 | FE | 10 km | SMF | COM | No |
GLC-FE-100EX= | 100BASE-EX | FE | 40 km | SMF | COM | No |
GLC-FE-100ZX= | 100BASE-ZX | FE | 80 km | SMF | COM | No |
GLC-FE-100BX-D= | 100BASE-BX10 | FE | 10 km | SMF | COM | No |
GLC-FE-100BX-U= | 100BASE-BX10 | FE | 10 km | SMF | COM | Sim |
GLC-SX-MM-RGD= | 1000BASE-SX | GE | 550 metrosetrosetrosetros | MMF | IND | Sim |
GLC-LX-SM-RGD= | 1000BASE-LX/LH | GE | 550 m/10 km | MMF/SMF | IND | Sim |
GLC-ZX-SM-RGD= | 1000BASE-ZX | GE | 70 km | SMF | IND | Sim |
GLC-BX40-U-I= | 1000BASE-BX40 | GE | 40 km | SMF | IND | Sim |
GLC-BX40-D-I= | 1000BASE-BX40 | GE | 40 km | SMF | IND | Sim |
GLC-BX80-U-I= | 1000BASE-BX80 | GE | 80 km | SMF | IND | Sim |
GLC-BX80-D-I= | 1000BASE-BX80 | GE | 80 km | SMF | IND | Sim |
GLC-SX-MMD= | 1000BASE-SX | GE | 550 m | MMF | EXT | Sim |
GLC-LH-SMD= | 1000BASE-LX/LH | GE | 550 m/10 km | MMF/SMF | EXT | Sim |
GLC-EX-SMD= | 1000BASE-EX | GE | 40 km | SMF | EXT | Sim |
GLC-ZX-SMD= | 1000BASE-ZX | GE | 70 km | SMF | EXT | Sim |
GLC-BX-D= | 1000BASE-BX10 | GE | 10 km | SMF | COM | Sim |
GLC-BX-U= | 1000BASE-BX10 | GE | 10 km | SMF | COM | Sim |
CWDM-SFP-xxxx= | CWDM 1000BASE-X | GE | SMF | COM | Sim | |
DWDM-SFP-xxxx= | DWDM 1000BASE-X | GE | SMF | COM | Sim | |
SFP-GE-S= | 1000BASE-SX | GE | 550 m | MMF | EXT | Sim |
SFP-GE-L= | 1000BASE-LX/LH | GE | 550 m/10 km | MMF/SMF | EXT | Sim |
SFP-GE-Z= | 1000BASE-ZX | GE | 70 km | SMF | EXT | Sim |
GLC-SX-MM= | 1000BASE-SX | GE | 550 m | MMF | COM | No |
GLC-LH-SM= | 1000BASE-LX/LH | GE | 550 m/10 km | MMF/SMF | COM | No |
GLC-ZX-SM= | 1000BASE-ZX | GE | 70 km | SMF | COM | Sim |
GLC-TE=2 | 1000BASE-T | GE | 100 metrosetrosetros | Cobre | EXT | NA |
GLC-T=2 | 1000BASE-T | GE | 100 m | Cobre | COM | NA |
GLC-T-RGD=2 | 1000BASE-T | GE | 100 m | Cobre | IND | NA |
ONS-SI-GE-SX= | 1000BASE-SX | GE | 500 metros | MMF | IND | |
ONS-SI-GE-LX= | 1000BASE-LX | GE | 10 km | SMF | IND | |
ONS-SI-GE-EX= | 1000BASE-EX | GE | 40 km | SMF | IND | |
ONS-SI-GE-ZX= | 1000BASE-ZX | GE | 80 km | SMF | IND | |
ONS-SE-GE-BXU= | 1000BASE-BX | GE | 10 km | SMF | EXT | |
ONS-SE-GE-BXD= | 1000BASE-BX | GE | 10 km | SMF | EXT | |
GLC-BX-U-I= | 1000BASE-BX | GE | 10 km | SMF | IND | |
GLC-BX-D-I= | 1000BASE-BX | GE | 10 km | SMF | IND | |
SFP-10G-BXD-I= | 10GBASE-BX | 10G | 10 km | SMF | IND | Sim |
SFP-10G-BXU-I= | 10GBASE-BX | 10G | 10 km | SMF | IND | Sim |
SFP-10G-BX40D-I= | 10GBASE-BX | 10G | 40 km | SMF | IND | Sim |
SFP-10G-BX40U-I= | 10GBASE-BX | 10G | 40 km | SMF | IND | Sim |
SFP-10G-SR-X= | 10GBASE-SR | 10G | 400 metrosetrosetrosetros | MMF | EXT | Sim |
SFP-10G-SR-I= | 10GBASE-SR | 10G | 400 m | MMF | IND | Sim |
SFP-10G-LR-X= | 10GBASE-LR | 10G | 10 km | SMF | EXT | Sim |
SFP-10G-SR= | 10GBASE-SR | 10G | 400 m | MMF | COM | Sim |
SFP-10G-LR= | 10GBASE-LR | 10G | 10 km | SMF | COM | Sim |
SFP-10G-ER= | 10GBASE-ER | 10G | 40 km | SMF | COM | Sim |
SFP-10G-ZR= | 10GBASE-ZR | 10G | 80 km | SMF | COM | Sim |
SFP-H10GB-CUxM= | Cabo Twinax | 10G | 1m, 3m, 5m | - | COM | - |
SFP-H10GB-ACUxM= | Cabo Twinax | 10G | 7m, 10m | - | COM | - |
ONS-SI+-10G-SR= | 10GBASE-SR | 10G | 400 m | MMF | IND | Sim |
ONS-SI+-10G-LR= | 10GBASE-LR | 10G | 10 km | SMF | IND | Sim |
ONS-SI+-10G-ER= | 10GBASE-ER | 10G | 40 km | SMF | IND | Sim |
ONS-SI+-10G-ZR= | 10GBASE-ZR | 10G | 80 km | SMF | IND | Sim |
SFP-10G-ER-I= | 10GBASE-ER | 10G | 40 km | SMF | IND | Sim |
SFP-10G-ZR-I= | 10GBASE-ZR | 10G | 80 km | SMF | IND | Yes |
SFP-10G-T-X= | 10GBASE-T | 10G | 30 m | Cobre | EXT | NA |
SFP-10G-LR10-I= | 10GBASE-LR | 10G | 10 km | SMF | IND | Yes |
DWDM-SFP10G-xxxx= | DWDM 10GBASE-X | 10G | SMF | COM | Yes | |
CWDM-SFP10G-xxxx= | CWDM 10GBASE-X | 10G | SMF | COM | Yes |
1If nonindustrial SFPs (EXT, COM) are used, the switch operating temperature must be derated.2Degrades PTP performance.
Ordering information
Table 16 lists the ordering information for the Cisco Catalyst IE9300 Rugged Series switches.
Table 16. Ordering information
Product ID | Descrição | |
IE-9310-26S2C-E | Catalyst IE9300 w/ 24 Ports GE SFP Downlinks and 4 Ports GE SFP uplinks, NE | |
IE-9310-26S2C-A | Catalyst IE9300 w/ 24 Ports GE SFP Downlinks and 4 Ports GE SFP uplinks, NA | |
IE-9320-26S2C-E | Catalyst IE9300 w/ 24 Ports GE SFP Downlinks and 4 Ports GE SFP uplinks, Stackable, NE | |
IE-9320-26S2C-A | Catalyst IE9300 w/ 24 Ports GE SFP Downlinks and 4 Ports GE SFP uplinks, Stackable, NA | |
IE-9320-22S2C4X-E | Catalyst IE9300 w/ 24 Ports GE SFP Downlinks and 4 Ports 10G SFP+ uplinks, Stackable, NE, Conformal Coating | |
IE-9320-22S2C4X-A | Catalyst IE9300 w/ 24 Ports GE SFP Downlinks and 4 Ports 10G SFP+ uplinks, Stackable, NA, Conformal Coating | |
IE-9320-24P4S-E | Catalyst IE9300 w/ 24 Ports GE PoE+ Downlinks and 4 Ports GE SFP uplinks, Stackable, NE | |
IE-9320-24P4S-A | Catalyst IE9300 w/ 24 Ports GE PoE+ Downlinks and 4 Ports GE SFP uplinks, Stackable, NA | |
IE-9320-24T4X-E | Catalyst IE9300 w/ 24 Ports GE Cu Downlinks and 4 Ports 10G SFP+ uplinks, Stackable, NE | |
IE-9320-24T4X-A | Catalyst IE9300 w/ 24 Ports GE Cu Downlinks and 4 Ports 10G SFP+ uplinks, Stackable, NA | |
IE-9320-24P4X-E | Catalyst IE9300 w/ 24 Ports GE PoE+ Downlinks and 4 Ports 10G SFP+ uplinks, Stackable, NE | |
IE-9320-24P4X-A | Catalyst IE9300 w/ 24 Ports GE PoE+ Downlinks and 4 Ports 10G SFP+ uplinks, Stackable, NA | |
IE-9320-16P8U4X-E | Catalyst IE9300 w/ 16 Ports GE PoE+ and 8 Ports 2.5G 4PPoE Downlinks and 4 Ports 10G SFP+ uplinks, Stackable, NE | |
IE-9320-16P8U4X-A | Catalyst IE9300 w/ 16 Ports GE PoE+ and 8 Ports 2.5G 4PPoE Downlinks and 4 Ports 10G SFP+ uplinks, Stackable, NA | |
SD-IE-4GB= | 4GB SD memory card for IE | |
CAB-STK-0.5M= | Cisco 0.5M stack cable | |
CAB-STK-1M= | Cisco 1M stack cable | |
RM-RGD-19IN= | Spare 19IN rack-mount kit | |
RM-RGD-23IN= | 23IN NEBS rack-mount kit | |
RM-RGD-ETSI= | ETSI rack-mount kit | |
PWR-RGD-AC-DC-H | Hazloc Power Supply High AC/DC 85-264VAC/88-300VDC | |
PWR-RGD-AC-DC-H= | Spare Hazloc Power Supply High AC/DC 85-264VAC/88-300VDC | |
PWR-RGD-LOW-DC-H | Hazloc Power Supply Low DC 24-60V/10A | |
PWR-RGD-LOW-DC-H= | Spare Hazloc Power Supply Low DC 24-60V/10A | |
PWR-RGD-AC-DC-250 | Hazloc Power Supply 100-240VAC/100-250VDC | |
PWR-RGD-AC-DC-250= | Spare Hazloc Power Supply 100-240VAC/100-250VDC | |
PWR-RGD-AC-DC-400 | Hazloc Power Supply 100-240VAC/100-250VDC, 400W | |
PWR-RGD-AC-DC-400= | Spare Hazloc Power Supply 100-240VAC/100-250VDC, 400W | |
IE9300-NW-A= | Network Advantage License for IE9300, Perpetual | |
IE9300-DNA-E | Cisco Catalyst Center DNA Essentials license for IE9300 Series | |
IE9300-DNA-E-3Y | IE 9300 Cisco Catalyst Center DNA Essentials, 3 Year Term license | |
IE9300-DNA-E-5Y | IE 9300 Cisco Catalyst Center DNA Essentials, 5 Year Term license | |
IE9300-DNA-E-7Y | IE 9300 Cisco Catalyst Center DNA Essentials, 7 Year Term license | |
IE9300-DNA-A | Cisco Catalyst Center DNA Advantage license for IE9300 Series | |
IE9300-DNA-A-3Y | IE 9300 Cisco Catalyst Center DNA Advantage, 3 Year Term license | |
IE9300-DNA-A-5Y | IE 9300 Cisco Catalyst Center DNA Advantage, 5 Year Term license | |
IE9300-DNA-A-7Y | IE 9300 Cisco Catalyst Center DNA Advantage, 7 Year Term license | |
Warranty
Five-year limited hardware warranty on all IE9300 product IDs and power supplies (see Table 15 above). See the following link for more details on the warranty: https://www.cisco.com/c/en/us/products/warranties/warranty-doc-c99-740591.html.
Cisco environmental sustainability
Information about Cisco’s environmental sustainability policies and initiatives for our products, solutions, operations, and extended operations or supply chain is provided in the “Environment Sustainability” section of Cisco’s Corporate Social Responsibility (CSR) Report.
Reference links to information about key environmental sustainability topics (mentioned in the “Environment Sustainability” section of the CSR Report) are provided in the following table:
Sustainability topic | Reference |
Information on product material content laws and regulations | |
Information on electronic waste laws and regulations, including products, batteries, and packaging |
Reference links to product-specific environmental sustainability information that is mentioned in relevant sections of this data sheet are provided in the following table:
Sustainability topic | Reference |
Power | |
Power specifications and consumption | |
Environmental characteristics | |
Operating temperature, industry standards, EMC emissions | |
Material | |
Unit weight | |
Cisco makes the packaging data available for informational purposes only. It may not reflect the most current legal developments, and Cisco does not represent, warrant, or guarantee that it is complete, accurate, or up to date. This information is subject to change without notice.
For information on services, visit https://www.cisco.com/web/services/.
Flexible payment solutions to help you achieve your objectives
Cisco Capital® makes it easier to get the right technology to achieve your objectives, enable business transformation, and stay competitive. We can help you reduce the total cost of ownership, conserve capital, and accelerate growth. In more than 100 countries, our flexible payment solutions can help you acquire hardware, software, services, and complementary third-party equipment in easy, predictable payments. Saiba Mais.
For more information about the Cisco IE 9300 Series, visit https://www.cisco.com/go/ie9300 or contact your local account representative.
For more datasheets, please go to the Download tab on each product details page, or search in the Datasheet Download Center.
Cisco Industrial Ethernet (IE) Switches
For Cisco product list and quote, please visit: https://www.hi-network.com/categories/cisco or contact us at www.hi-network.com (Email: [email protected])
Tags quentes :
CISCO Switches
datasheet
Cadastre-se agora para Ações Semanais de Promoção
100% free, Unsubscribe any time!
Add 1: Room 605 6/F FA YUEN Commercial Building, 75-77 FA YUEN Street, Mongkok KL, HongKong Add 2: Room 405, Building E, MeiDu Building, Gong Shu District, Hangzhou City, Zhejiang Province, China
Whatsapp/Tel: +8618057156223 Tel: 0086 571 86729517 Tel em HK: 00852 66181601
Email: [email protected]
English
Pусский
Français
Español
Português
